250-5000 kgs capacity lifter for steel or concrete handling with control arm for easy manipulation
Ideal for machine loading ferrous and non-ferrous plates
Site handling of concrete panels/stone
sheets
No external power source required - cable free
Available with site friendly 110volt integral charger
Full audio/visual low vacuum alarm
Optional radio control for suction and release
Model: D4KB for Thicker Plates/Concrete/Stone
OTHER MODELS D1KB(1000KGS) , D2KB(2000KGS)D3KB(3000KGS) - D20KB(20,000KGS)
4000 kg capacity 2 pad lifter
Battery powered for heavier plates
Concrete/stone, built in charger from 100 - 300 volts input
Runs for 2/3 days between charges
Heavy duty pads to any size (square, rectangular narrow)
With replaceable rubber seal
Single lift point for low headroom cranes
Optional radio controlled solenoid valve
2 pad units available from 250-20,000 kgs
Model: QFXC for Sheets & Panels
FOR USE WITH CRANE OR FORKLIFT
1000 kg capacity dual use unit for forklift or crane
4 pad unit with 2 cross beams
Battery powered with built in charger
Ideal for laser cutters, sheet metal, panels
Available with radio remote capacities
from 250 - 10,000 kgs
Model: SKDT5KB for Concrete slabs/ heavy plates
For heavy duty slab handling
for straight or side lifting
No external power source required
Installation free
Units from 2000 - 10,000 kgs
capacity
Model: QL12KB 4 Pad Lifter for Long Plates
Heavy duty battery powered lifter for use with overhead crane
Exchangeable battery pack for 24/7 operations
Available with manual or radio control.
units from 2 - 30 tons capacity
Model: SFC For Plates/Concrete/Stone
Compact unit for use with either crane
or forklift
With capacities from 500-3000kgs
No external power source required
Cable free
Model: SQUAREBACK Single Pad Lifter from 100-1500 kgs Capacity
FOR STEEL/CONCRETE & STONE FOR STRAIGHT
Single pad lifter for workshop or site
Portable vacuum supply unit -only
weighs 26 kgs
Pads available with capacities up to
1500 kgs
Easily exchanged pads to suit your
range of requirements
vacuum pads available off the shelf:
from 250x250mm(120kg) to
950x600mm(1500kg)
We can manufacture Custom
dimensioned pads to suit your product
Built in audio-visual vacuum alarm
No external power source required
Cable free
Available with site friendly 110volt integral charger
Full audio/Visual low vacuum alarm
Optional radio control for suction and release
Model: ‘SUPERSOOKER’
OUR BEST SELLING Portable
vacuum lifting solution-for straight
and sidelifting of stone/concrete/
plates
For loads upto 1000 kgs/for use with
mini excavator/crane/ range of
vacuum pads available off the shelf,
eg. narrow kerb pads, square,
rectangular
Huge range of vacuum pads available off the shelf, eg. narrow kerb pads, dual pad sets, quad pads sets
Easily exchangeable pad system for kerbs/slabs/plates
Built in audio-visual vacuum alarm
Always in stock
Model: SKDAKB –Single Pad Lifter from 1000-10,000 kgs Capacity
FOR HEAVY PLATES/SLABS
Modular battery powered system with
Exchangeable pad
Integral charger
Available with remote control
Pads to any dimension
Model: QTKB – 1000 KG Capacity Lifter with 90 Degree Tilt
OTHER MODELS :
QT250B(250KG)QT500B(500KG)QT2KB(2000KG
TO QT10KB(10,000 KGS)
1000 - 10,000kgs capacity battery powered 4
pad lifters
Pads adjustable on cross beams
Cross beams adjustable on main beam
4 pad in line option for narrow sections
Safety factor 3
All pads with isolators for small pieces for stone.
For stone. Concrete/ Plates
Model: DECT10KB
Long Scale 10 Pad 5 x-beam 90 degree Tilt Lifter
For concrete panels / steel plates from 2 - 30 tons
No installation required - ideal for site work/fabrication yards
Units with 1,2,4,6,8,10 or more pads
Model: 5-20 ton revetment lifter
Ultra high specification battery powered
lifter for lifting a range of seawall /
revetment sections from 2 step to
multistep to flat slabs(exchangeable
pad sets)
Radio controlled
Safety factor 2
Exchangeable battery pack for 24/7
operation
Special custom built units to customers
specification on application
